4-24
X9DRG-HF/X9DRG-HTF Motherboard User’s Manual
iSCSIConguration: This item displays iSCSI conguration information:
iSCSI Initiator Name
This item displays the name of the iSCSI Initiator, which is a unique name used
in the world. The name must use IQN format. The following actions can also
be performed:
•Add an Attempt
•Delete Attempts
•Commit Changes and Exit
•Discard Changes and Exit
•Change Attempt Order
•Commit Changes and Exit
•Discard Changes and Exit
Intel® I350 Gigabit Network Connections: These items display the following
information on the Intel I350 LAN connections.
NICConguration
Link Speed
Use this feature to change the link speed and duplex for the current port. The op-
tions are AutoNeg, 10Mbps Half, 10Mbps Full, 100Mbps Half, and 100Mbps full.
Wake on LAN
Select enabled to wake the system with a magic packet. The options are Enabled
and Disabled.
Blink LEDs
This feature allows the user to specify the duration for LEDs to blink. The range is
from 0 ~ 15 seconds. The default setting is 0.
PORT CONFIGURATION INFORMATION
This section displays the following port information:
•UEFI Driver
•Adapter PBA
