X9SCM-IIF/X9SCL-IIF Series User’s Manual
BIOS 64 Mb SPI AMI BIOS
®
SM Flash BIOS
Play and Plug (PnP0, DMI 2.3, PCI 2.3, ACPI 1.0/2.0/3.0,
USB Keyboard and SMBIOS 2.5
Power Management ACPI/ACPM Power Management
Complies with EuP Eco Design Directive
Main Switch Override Mechanism
Keyboard Wake-up from Soft-Off
Internal/External Modem Ring-On
Intel
®
Intelligent Power Node Manager
Manageability Engine
Power-on mode for AC power recovery
PC Health Monitoring CPU Monitoring
Onboard voltage monitors for CPU core, +3.3V, +5V, +/-
12V, +3.3V Stdby, VBAT, Memory
CPU 4-phase switching voltage regulator
CPU/System overheat LED and control
CPU Thermal Trip support
Thermal Monitor 2 (TM2) support
Fan Control
Fan status monitoring with rmware 4-pin (Pulse Width
Modulation) fan speed control
Low noise fan speed control
System Management PECI (Platform Environment Conguration Interface) 3.0
support
System resource alert via Supero Doctor III
SuperoDoctor III, Watch Dog, NMI
Chassis Intrusion header and detection
CD Utilities BIOS ash upgrade utility
Drivers and software for Intel® Cougar Point chipset utili-
ties
Other ROHS 6/6 (Full Compliance, Lead Free)
Disk On Module (DOM) Power Connector, TPM Header
Dimensions Micro ATX form factor (9.6" x 9.6") (243.84mm x
243.84mm)
Note: For IPMI Conguration Instructions, please refer to the Embedded
IPMI Conguration User's Guide available @ http://www.supermicro.com/
support/manuals/.
