X9SCM-IIF/X9SCL-IIF Series User’s Manual
1-9 Overview of the Nuvoton WPCM450 Controller
The Nuvoton WPCM450R Controller is a Baseboard Management Controller (BMC)
that supports 2D/VGA-compatible Graphics cores, Virtual Media, and Keyboard/
Video/Mouse Redirection (KVMR) modules. With blade-oriented Super I/O capability
built in, the WPCM450R Controller is ideal for legacy-reduced server platforms.
The WPCM450R interfaces with a host system via PCI interface to communicate
with the Graphics core. It supports USB 2.0 and 1.1 for remote keyboard/mouse/
virtual media emulation. It also provides LPC interface to control Super IO func-
tions. The WPCM450R is connected to the network via an external Ethernet PHY
module.
The WPCM450R communicates with onboard components via six SMBus inter-
faces, fan control, and Platform Environment Control Interface (PECI) buses.
Note: For more information on IPMI conguration, please refer to the
Embedded IPMI User's Guide posted on our Website @ http://www.su-
permicro.com/support/manuals/.
