Diagram 4 - Wiring Diagram - PRO 35 III Electric, 182602
Parts List
DIAG.
LOC.
PART
NO.
DESCRIPTION
QTY.
REQ.
1 176913 CABLE, CONTROL 1
2 182061 WIRING HARNESS, COWL 1
3 176914 TRANSFORMER, CURRENT 1
4 176915 STARTER, MOTOR CONTROL 1
5 176917 OVERLOAD RELAY 1
6 176838 CABLE, BATTERY, POSITIVE, HYD. 1
7 176714 CABLE, BATTERY, NEGATIVE, HYD. 1
8 176398 SWITCH, NEUTRAL SAFETY 1
9 166711 SWITCH, ROCKER 2
10 117154 ALTERNATOR 1
11 166622 BLOCK, FUSE 1
12 166708 RELAY, N.O. N.C. 2
13 166121 SOLENOID RELAY 1
14 178724 WATER PRESSURE SWITCH 1
15 166438 GAUGE, BATTERY VOLTS 1
16 176918 METER, MOTOR LOAD 1
17 163779 GAUGE, HOUR METER 1
18 166707 SWITCH, IGNITION 1
19 182100 HANDLE,TRANSMISSION/LIFT CONTROL 1
20 183433 CORD, 4 GA, 208/230 VOLT/20 HP (208/230V/20HP Only) 1
20 183402 CORD, 8 GA, 460/575 VOLT/20 HP, 575 VOLT/30 HP (460/575V/20HP & 575V/30HP Only) 1
20 176957 CORD, 6 GA, 460 VOLT/30 HP (460V/30HP Only) 1
21 163121 BATTERY, 12 VOLT 1
22 166633 HYDRAULIC PUMP ASSY 1
23 176383 E. STOP SWITCH 1
24 166594 COIL - 12V DC 1
25 164977 WATER PUMP, ASSY 1
26 178645 CIRCUIT BREAKER, 30 AMP 1
27 176949 OVERLOAD HEATER, 208 VOLT/20 HP (208V/20HP Only) 3
27 176948 OVERLOAD HEATER, 230 VOLT/20 HP (230V/20HP Only) 3
27 176947 OVERLOAD HEATER, 460 VOLT/20 HP (460V/20HP Only) 3
27 176946 OVERLOAD HEATER, 575 VOLT/20 HP (575V/20HP Only) 3
27 183361 OVERLOAD HEATER, 460 VOLT/30 HP (460V/30HP Only) 3
27 183337 OVERLOAD HEATER, 575 VOLT/30 HP (575V/30HP Only) 3
28 176931 CONNECTOR, 208/230 VOLT/20 HP (208/230V/20HP Only) 1
28 176942 CONNECTOR, 480 VOLT/20 HP (480V/20HP Only) 1
28 176944 CONNECTOR, 575 VOLT/20 & 30 HP (575V/20&30HP Only) 1
28 183403 CONNECTOR, 480 VOLT/30 HP (480V/30HP Only) 1
29 176930 PLUG, 208/230 VOLT/20 HP (208/230V/20HP Only) 1
29 176943 PLUG, 480 VOLT/20 HP (480V/20HP Only) 1
29 176945 PLUG, 575 VOLT/20 & 30 HP (575V/20&30HP Only) 1
29 183404 PLUG, 480 VOLT/30 HP (480V/30HP Only) 1
