6-1
Chapter 6
MegaRAID Window and Menus
The MegaRAID Storage Manager software is a configuration and monitoring utility used
with the Embedded MegaRAID Software. This chapter provides instruction on its use
and features.
6-1 Starting MegaRAID Storage Manager Software
Follow these steps to start MegaRAID Storage Manager software and view the main
window:
1. Start the program using the method required for your operating system
environment:
• To start MegaRAID Storage Manager software on a Microsoft Windows system,
select S
TART J PROGRAMS J MEGARAID STORAGE MANAGER J STARTUPUI, or
double-click the M
EGARAID STORAGE MANAGER shortcut on the desktop.
• To start MegaRAID Storage Manager software on a Red Hat Linux system,
select A
PPLICATIONS J SYSTEM TOOLS J MEGARAID STORAGE MANAGER J
S
TARTUPUI.
• To start MegaRAID Storage Manager software on a SUSE SLES 9 system,
select S
TART J SYSTEM J MORE PROGRAMS J MEGARAID STORAGE MANAGER.
When the program starts, the SELECT SERVER window appears (Figure 6-1).
NOTE: If a warning appears stating that Windows Firewall has blocked some
features of the program, click U
NBLOCK to allow MegaRAID Storage Manager
software to start.
This is because Windows Firewall sometimes blocks the operation of programs
that use Java.
