Chapter 1: Introduction
1-7
Introduction
ACPI Features
• Microsoft OnNow
• Slow blinking LED for suspend state indicator
• Main switch override mechanism
Onboard I/O
• Marvell SATA controller (*X6DAT-G only)
• One Intel 8254x Gigabit Ethernet controller (supports 1 GLAN port)
• 2 EIDE Ultra DMA/100 bus master interfaces
• 1 floppy port interface (up to 2.88 MB)
• 1 EPP/ECP Parallel Port
• PS/2 mouse and PS/2 keyboard ports
• Up to four USB 2.0 (Universal Serial Bus):
(2 Back Panel USB ports & 2 Front Panel USB headers)
• 2 serial (COM) ports
• 2 Intel 6300 ESB Serial ATA Headers w/RAID 0, 1 support
• 4 Marvell Serial ATA Headers (*X6DAT-G only)
• AC'97 Audio CODEC six-channel sound
Other
• Internal/external modem ring-on
• Wake-on-Ring (WOR)
• Wake-on-LAN (WOL)
• Console redirection
CD/Diskette Utilities
• BIOS flash upgrade utility and device drivers
Dimensions
• ATX Ext. 12" x 13.05" (304.8 x 331.5 mm)
