X6DAT-G/X6DAi-G User's Manual
Power Button
Overheat LED
1
NIC1 LED
Reset Button
2
Power Fail LED
HDD LED
Power LED
Reset
Pwr
Vcc
Vcc
Vcc
Vcc
Ground
Ground
1920
Vcc
X
Ground
NMI
X
x
x
NIC1 LED Indicator
The NIC1 (Network Interface Con-
troller) LED connections for the
GLAN port1 is located on pins 11
and 12 of JF1. Attach the NIC LED
cable to display network activity.
Refer to the tables on the right for
pin definitions.
NIC1 LED Pin
Definitions
(JF1)
Pin
Number
11
12
Definition
Vcc
GND
HDD LED
The HDD LED connection is located
on pins 13 and 14 of JF1. Attach
the hard drive LED cable here to
display disk activity (for any hard
drives on the system, including
Serial ATA and IDE). See the table
on the right for pin definitions.
HDD LED Pin
Definitions
(JF1)
Pin
Number
13
14
Definition
Vcc
HD Active
NIC1 LED
