3.2 Quick Installation Guide
With a Web-based utility, it is easy to configure and manage the TL-WR710N WiFi Pocket
Router/AP/TV Adapter/Repeater. The Web-based utility can be used on any Windows, Macintosh
or UNIX OS with a Web browser, such as Microsoft Internet Explorer, Mozilla Firefox or Apple
Safari.
1. To access the configuration utility, open a web-browser and type in the default address
http://tplinklogin.net in the address field of the browser.
After a moment, a login window will appear, similar to the Figure 3-3. Enter admin for
the
User Name and Password, both in lower case letters. Then click the OK button or press the
Enter key.
Figure 3-3 Login Windows
)
Note:
If the above screen does not pop-up, it means that your Web-browser has been set to a proxy. Go
to Tools menu>Internet Options>Connections>LAN Settings, in the screen that appears, cancel
the Using Proxy checkbox, and click OK to finish it.
2. After a successful login, you can click the Quick Setup menu to quickly configure your
Router.
Figure 3-4 Quick Setup
