Part number Description Table and page
IR4044P525NI Power supply Bottom unit assembly
on page 189
NS-SCR-00027NI Screw, ADF, wave 3x10 ADF Assembly on page 171
NS-SCR-00027NI Screw, wave 3x10 Keyboard assembly
on page 197
NS-SCR-00056NI Screw, ADF, wave 4x10 ADF Assembly on page 171
NS-SCR00016NI Screw, ADF, 03T060SR-W ADF Assembly on page 171
PF2282K034NI Separation pad case Separation pad case
on page 175
PF2282K035NI Separation pad Customer-replaceable
components on page 163
PF2282K039NI Pickup roller assembly Customer-replaceable
components on page 163
PF2282K040NI Pickup roller cover Customer-replaceable
components on page 163
PF2282K043NI Mylar holder assembly Customer-replaceable
components on page 163
PF2282P025NI White mylar backing ADF Assembly on page 171
PF2282P039NI ADF pickup gear Pickup roller assembly
on page 177
PF2282P339NI White scan background ADF Assembly on page 171
PF2282P343NI White mylar backing springs ADF Assembly on page 171
PF2284-SVPNI ADF assembly ADF Assembly on page 171
PF2284K012NI ADF left cover ADF left cover on page 183
PF2284K015NI Control-panel cover assembly Control-panel cover assembly
on page 179
PF2284K042NI Paper input tray, ADF Customer-replaceable
components on page 163
PF2284K042Nl Paper input tray, ADF ADF input tray assembly
on page 185
PF2284K151NI ADF jam access latch Pickup roller assembly
on page 177
PF2284K152NI Clear plastic paper guide Pickup roller assembly
on page 177
PF2284K153NI Hinge flaps Customer-replaceable
components on page 163
PF2284K500NI ADF cable ADF Assembly on page 171
PF2284P044NI ADF right cover ADF Assembly on page 171
PF2284P060NI Output bin base cover ADF base assembly
on page 173
Table 7-24 Numerical parts list (continued)
212 Chapter 7 Parts and diagrams ENWW
