Scanner front cover
1. Remove the following covers:
Scanner right cover. See
Scanner right cover on page 73.
Scanner left cover. See
Scanner left cover on page 74.
2. Remove three screws (callout 1).
1
Figure 5-52 Removing the scanner front cover
3. Remove the scanner front cover.
ENWW External components and covers 75
