Chapter 3 PXI-8170 Series Installation
PXI-8170 Series User Manual 3-6 www.ni.com
Figure 3-3 shows a PXI-8170 installed in the system controller slot of a
National Instruments PXI-1000 mainframe. You can place PXI devices in
any other slot.
Figure 3-3. PXI-8170 Installed in a PXI Mainframe
1 PXI-1000B Chassis
2 PXI-8170 System Controller
3 PXI Board
4 Injector/Ejector Handle
5 Injector/Ejector Rail
3
1
2
4
5
