X8ST3-F/X8STE Jumpers
JPUSB3 #19 FP USB 2, 3 Wake-up Pins 1-2 (Enabled)
JWD #53 Watch Dog Timer Enable Pins 1-2 (Reset)
X8ST3-F/X8STE Headers/Connectors
Connector
Label
Description
Battery #45 Onboard battery (B1)
COM1/COM2 #3, 11 COM1/2 Serial connection headers
Fans 1~5 #58, 52, 34, 33, 7 System/CPU fan headers (Fan 1: CPU fan)
Floppy #12 Floppy Disk Drive connector
I-Button #42 I-Button for RAID data storage
JAR #50 Alarm Reset
JD1 #51 Speaker header (Pins 3/4: Internal, 1~4:External)
JF1 #55 Front Panel Control header
JL1 #36 Chassis Intrusion header
JLED #57 Power LED Indicator header
JOH #54 Overheat LED header
JPW1 #59 24-pin ATX main power connector (required)
JPW2 #61 +12V 8-pin CPU power connector (required)
JWOL #43 Wake-On-LAN header
KB/Mouse #1 Keyboard/mouse connectors
LAN1/LAN2 #5, 6 Gigabit Ethernet (RJ45) ports
(IPMI) LAN #2 IPMI Dedicated LAN (X8ST3-F only)
I-SATA 0~5 #40, 41, 49 Serial_ATA ports
SAS 0~3, 4~7 #20~23, 27, 28,
30, 31
Serial Attached SCSI Ports (X8ST3-F only)
SMB_PS1 #60 PWR supply (I
2
C) System Management Bus
SPKR1 #46 Internal speaker/buzzer
3-SGPIO-0/1 #24, 25 Serial_link IO headers for SAS (X8ST3-F)
T-SGPIO-0/1 #48, 47 Serial General Purpose IO headers (for SATA)
USB 0~1 #2 (Backpanel) Universal Serial Bus (USB) ports
USB 2, USB 3,
USB4/5, 6/7
#17, 18, 38, 39 Front panel accessible USB headers
VGA #4 Video Port
X8ST3-F/X8STE LED Indicators
LED
Label
Description
LE1 #56 Onboard Standby PWR warning LED Indicator
LES1 #32 SAS Activity (Blinking: SAS Active) (X8ST3-F only)
LES2 #29 SAS Heartbeat (Blinking: SAS Normal) (X8ST3-F only)
