1-8
X8ST3-F/X8STE User’s Manual
Keyboard Wake-up from Soft-Off•
USB Wake-up from Soft-Off•
Wake-on-LAN•
Power-on mode for AC power recovery•
PC Health Monitoring
CPU Monitoring
Onboard voltage monitors for CPU core, Memory Voltage, Chipset Voltage, •
+1.8V, +3.3V, +3.3V standby, +5V, +5V, Standby, VBat and ±12V
CPU 6-Phase-switching voltage regulator•
CPU/System overheat LED and control•
CPU Thermal Trip support•
Thermal Monitor 2 (TM2) support•
Fan Control
Fan status monitoring with rmware 4-pin (Pulse Width Modulation) fan •
speed control
Low noise fan speed control•
System Management
PECI (Platform Environment Conguration Interface) support•
System resource alert via Supero Doctor III •
SuperoDoctor III, Watch Dog, NMI•
I•
2
C temperature sensing logic
Chassis Intrusion Header and Detection•
Pb Free•
CD Utilities
BIOS ash upgrade utility•
Drivers and software for Intel® X58 Express chipset utilities •
Dimensions
ATX form factor, 12" x 10" (304.8 x 254.0 mm)•
