4-22
X8ST3-F/X8STE User’s Manual
Channel Number - Enter the channel number for the SET LAN Cong com-
mand. This is initially set to [1]. Press "+" or "-" on your keyboard to change
the Channel Number.
Channel Number Status - This feature returns the channel status for the
Channel Number selected above: "Channel Number is OK" or "Wrong Channel
Number".
IP Address - Enter the IP address for this machine. This should be in decimal
and in dotted quad form (i.e., 192.168.10.253). The value of each three-digit
number separated by dots should not exceed 255.
MAC Address - The BIOS will automatically enter the MAC address of this
machine, however it may be over-ridden. MAC addresses are 6 two-digit hexa-
decimal numbers (Base 16, 0 ~ 9, A, B, C, D, E, F) separated by dots. (i.e.,
00.30.48.D0.D4.60)
Subnet Mask - Subnet masks tell the network which subnet this machine be-
longs to. The value of each three-digit number separated by dots should not
exceed 255.
SetPEFConguration
Set this feature to congure the Platform Event Filter (PEF). PEF interprets BMC
events and performs actions based on pre-determined settings or 'traps' under IPMI
1.5 specications. For example, powering the system down or sending an alert
when a triggering event is detected.
The following will appear if PEF Support is set to Enabled. The default is Dis-
abled.
PEF Action Global Control - These are the different actions based on BMC
events. The options are Alert, Power Down, Reset System, Power Cycle, OEM
Action, Diagnostic Interface.
Alert Startup Delay - This feature inserts a delay during startup for PEF alerts.
The options are Enabled and Disabled.
PEF Alert Startup Delay - This sets the pre-determined time to delay PEF
alerts after system power-ups and resets. Refer to Table 24.6 of the IPMI 1.5
Specication for more information at www.intel.com. The options are No Delay,
30 sec, 60 sec, 1.5 min, 2.0 min.
Startup Delay - This feature enables or disables startup delay. The options are
Enabled and Disabled.
PEF Startup Delay - This sets the pre-determined time to delay PEF after
system power-ups and resets. Refer to Table 24.6 of the IPMI 1.5 Specication
for more information at www.intel.com. The options are No Delay, 30 sec, 60
sec, 1.5 min, 2.0 min.
