Q1860-90918 8 Parts and diagrams 293
Toner cartridge door assembly RG5-3556-040CN Figure 163 on page 265
Control panel assembly RG5-5438-030CN Figure 163 on page 265
Cover, control panel LED RB2-1758-000CN Figure 163 on page 265
Cover, front inner RG5-3547-040CN Figure 162 on page 264
Tray 1 sensor arm RB1-6134-030CN Figure 162 on page 264
Tray 1 paper guide RG5-3548-000CN Figure 162 on page 264
Cover, front Q1860-67904 Figure 162 on page 264
Cover, left side RG5-3550-000CN Figure 162 on page 264
Cover, rear RG5-3551-040CN Figure 162 on page 264
Strap, rear output support RB2-1977-000CN Figure 162 on page 264
Face-up tray assembly RG5-3552-000CN Figure 162 on page 264
Pin, front cover RB2-1745-000CN Figure 162 on page 264
Cover, right side RB2-1749-000CN Figure 162 on page 264
Cover, face-down auxiliary RB2-1747-000CN Figure 162 on page 264
Cover, right corner RB2-1755-000CN Figure 162 on page 264
Cover, left corner RB2-1756-000CN Figure 162 on page 264
Overlay, English (other languages available) C4110-40004 Figure 162 on page 264
Table 88. Alphabetical parts list (continued)
Description Part number Figure and page
