52 Printer operation Q1860-90918
PCL FONT
SOURCE=INTERNAL
INTERNAL
SOFT
SLOT 1, 2, or 3
INTERNAL
: Internal fonts.
SOFT: Permanent soft fonts.
SLOT 1, 2, or 3: Fonts stored in one of the three DIMM
slots.
PCL FONT
NUMBER=0
0 to 999
The printer assigns a number to each font and lists the
numbers on the PCL Font List. The font number appears in
the Font # column of the printout.
PCL FONT
PITCH= 10.00
0.44 to 99.99
This item might not appear, depending on the font selected.
Press [-Value+] once to change the setting by an increment
of .01 for pitch, or hold down [-Value+] to scroll by
increments of 1.
PCL FONT
SIZE=12.00
4.00 to 999.75
This item might not appear, depending on the font selected.
Press [-Value+] once to change setting by an increment of
.25 for point size, or hold down [-Value+] to scroll by
increments of 1.
PCL SYMBOL
SET=PC-8
PC-8
many others
Select any one of several available symbol sets from the
printer control panel. A symbol set is a unique grouping of all
the characters in a font. PC-8 or PC-850 is recommended for
line-draw characters. See the user guide for more information
about symbol-set charts.
COURIER=REGULAR REGULAR
DARK
Select the version of Courier font to use:
REGULAR: The internal Courier font that is available on the
HP LaserJet 4 series printers.
DARK: The internal Courier font that is available on the HP
LaserJet III series printers.
These two fonts are not available at the same time.
WIDE A4=NO NO
YES
The Wide A4 setting changes the number of characters that
can be printed on a single line of A4 paper.
NO: Up to 78 10-pitch characters can be printed on one line.
YES: Up to 80 10-pitch characters can be printed on one line.
APPEND CR TO LF=
NO
NO
YES
Select YES to append a carriage return to each line feed that
is encountered in backward-compatible PCL jobs (pure text,
no job control). Some environments, such as UNIX, indicate
a new line using only the line-feed control code. This option
allows the user to append the required carriage return to each
line feed.
PRINT PS
ERRORS=OFF
OFF
ON
Select ON to print the PS error page when PS errors occur.
Table 19. Printing menu
Item Values Explanation
